One Partner. Complete Control.
Powered by additive manufacturing technologies
Designed to reduce expenditures by up to 40%
Steel, copper, and next-gen conformally cooled plungers
We engineer injection systems that:
Faster output, higher productivity
Fewer breakdowns, less downtime
Efficiency that pays back every shot
From first concept to production-ready part, our engineers work with you to define your needs and design the right solution.
Our engineering team combines extensive experience in the die-casting process with deep knowledge of materials, thermal dynamics, and advanced manufacturing to design, simulate, test, and produce high-performance components – entirely in-house.
We use advanced simulations to solve the most demanding die-casting challenges.
From small to giga casting components, every size has the same precision, reliability, and performance results.
DIMENSIONS (MM)
DIAMETER 90mm
HEIGHT 79mm
LENGTH 789mm
WIDTH 785mm
HEIGHT 250mm
We own the entire process.
Starting with our in-house premium tool steel stock, through machining, heat treatment, and advanced metal additive manufacturing, we keep every step under one roof.
Advanced conformally cooled solutions for superior thermal management.
Enhanced lifetime combined with shorter cycle time leads to relevant cost reduction
innoSleeve is a cutting-edge and environmentally friendly shot sleeve solution designed to reduce sleeve expenditures by up to 40%.
Conducta, Endura, and Performa –
is engineered to directly tackle your main concerns: maximizing efficiency, minimizing downtime, and ensuring quality control.
STEEL PLUNGER
Cooling performance ●●●○
Machine misalignment tolerance ●●●
Vacuum application ●●●
Structural parts ●●●
Range of Ø 40-260 mm
Machine size range Small - Large
Versions Solid, with ring, with ring & sprue bush
Locking system Bayonet or thread. Bullet nose version available
Lead time Available from stock
COPPER PLUNGER
Cooling performance ●●●●
Machine misalignment tolerance ●●○
Vacuum application ●●●
Structural parts ●●●
Range of Ø 40-260 mm
Machine size range Small - Large
Versions Solid, with ring, with ring & sprue bush
Locking system Bayonet
Lead time Available from stock
CONFORMALLY COOLED PLUNGER
Cooling performance ●●●○
Machine misalignment tolerance ●○○
Vacuum application ●●●
Structural parts ●●●
Range of Ø 70-200 mm
Machine size range Med - Large
Versions Solid, with ring, with ring & sprue bush
Locking system Thread. Bullet nose version available
Lead time Available from stock
Main material Steel
Cooling performance ●●●○
Machine misalignment tolerance ●○○
Vacuum application ●●●
Structural parts ●●●
Range of Ø 70-200
Machine size range Med - Large
Versions Solid, with ring, with ring & sprue bush
Locking system Thread. Bullet nose version available
Lead time Available from stock
 |  |  | |
|---|---|---|---|
STEEL PLUNGER | COPPER PLUNGER
| CONFORMALLY COOLED PLUNGER
| |
Cooling performance | ● ● ● ○ | ● ● ● ● | ● ● ● ○ |
Machine misalignment tolerance | ● ● ● | ● ● ○ | ● ○ ○ |
Vacuum application | ● ● ● | ● ● ● | ● ● ● |
Structural parts | ● ● ● | ● ● ● | ● ● ● |
Range | Ø 40-260mm | Ø 40-260mm | Ø 70-200mm |
Machine size range | Small – Large | Small – Large | Med – Large |
Versions | Solid, with ring, with ring & sprue bush | Solid, with ring, with ring & sprue bush | Solid, with ring, with ring & sprue bush |
Locking system | Bayonet or thread. Bullet nose version available | Bayonet | Thread. Bullet nose version available |
Lead time | Available from stock | Available from stock | Available from stock |
 | | |
Have a question or need more information? Leave us a message, and we’ll get back to you as soon as possible.
